Nema 23 x 51mm Stepper Motor

Nema 34 x 80mm Stepper Motor

Shipping calculated at checkout.

Nema 34 x 80mm Stepper Motor


NEMA 34 stepper motors are used on big 3D printers and CNC machines.  This is a high torque, bi-polar, 4-wire stepper motor and comes with 300mm leads.


Nema 34 x 80mm Stepper Motor Specifications:


  • Size: NEMA 34 (86mm x 86mm)

  • Length: 80mm

  • Step angle: 1.8 Degrees

  • Rated voltage: 1.6V

  • Current/Phase: 4A

  • Resistance/Phase: 0.4 Ohm

  • Inductance/Phase: 2.13 mH

  • Holding Torque: 42 kg.cm (4.2 Nm)

  • Number of leads: 4

  • Rotor inertia: 1.4 g.cm^2

  • Weight: 3.0 kg


NEMA 23 stepper motors are used on big 3D printers and CNC machines.  This is a high torque, bi-polar, 4-wire stepper motor and comes with 300mm leads.
